Detailed description
2.12 Block descriptions
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-97
Signal I/O Type Value range Remarks
BHGInLen I Byte HHU default:
B#16#6 (6 bytes)
Quantity of data received from
handheld unit
BHGOutLen I Byte HHU default:
B#16#14 (20 bytes)
Quantity of data transmitted to
handheld unit
BHGTimeout I S5time Recommendation:
700 ms
Cyclic sign-of-life monitoring for
handheld unit
BHGCycl I S5time Recommendation:
100 ms
Time reference for cyclic updating
of signals to handheld unit
BHGRecGDNo I Int HHU default: 2 Receive GD circle no.
BHGRecGBZNo I Int HHU default: 2 Receive GI no.
BHGRecObjNo I Int HHU default: 1 Object number for receive GI
BHGSendGDNo I Int HHU default: 2 Transmit GD circle no.
BHGSendGBZNo I Int HHU default: 1 Transmit GI no.
BHGSendObjNo I Int HHU default: 1 Object number for transmit GI
BHGMPI I Bool 1: Handheld unit coupled to MPI
(without SDB 210 config.)
Parameter HHU must be set to 2.
BHGStop I Bool 0: Start transmission
of handheld unit signals
1: Stop transmission
of handheld unit signals
BHGNotSend I Bool 0: Send and receive operation
activated
1: Receive HHU signals only
(under development)
NCCyclTimeout I S5time Recommendation:
200 ms
Cyclic sign-of-life monitoring NCK
NCRunupTimeout I S5time Recommendation:
50 s
Powerup monitoring NCK
ListMDecGrp I Int 0...16 Activation of expanded
M group decoding
0: Not active
1...16: Number of M groups
NCKomm I Bool PLC NC communications services
(FB 2/3/4/5/7:
Put/Get/PI_SERV/GETGUD)
true: active
MMCToIF I Bool Transmission of MMC signals to
interface (modes, program control,
etc.)
true: active
HWheelMMC I Bool True: Handwheel selection via
MMC
False: Handwheel selection via
user program
