2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
2-80 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2.9 2.9 Mode group, channel, program operation, reset response (K1)
2.9.1 Signals to mode group (DB11)
DB11, ...
DBX0.0
AUTOMATIC mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
AUTOMATIC mode is selected by the PLC program.
Signal state 0 or
edge change
1 → 0
AUTOMATIC mode is not selected by the PLC program.
Signal irrelevant
for ...
DB11, ... DBX0.4 (operating mode, changeover inhibit) = 1
Corresponding to .... DB11, ... DBX6.0 (active AUTOMATIC mode)
DB11, ...
DBX0.1
MDA mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
MDA mode is selected by the PLC program.
Signal state 0 or
edge change
1 → 0
MDA mode is not selected by the PLC program.
Signal irrelevant
for ...
DB11, ... D0.4 (operating mode, changeover inhibit) = 1
Corresponding to .... DB11, ... DBX6.1 (active MDA mode)
