Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-1
Detailed Description
2
2.1 2.1 Key PLC CPU data for 810D, 840D and 840Di
The tables below show the performance range of the PLC CPUs and the scope of the
basic PLC program relative to the various controller types.
Type of control: 810D and 840D
Key CPU data
810D / 840D 810D / 840D 810D / 840D
PLC CPU
MLFB
Integrated PLC
CPU314
Integrated PLC
CPU315-2DP
6ES7 315-2AF00-0AB0
Integrated PLC
CPU315-2DP master/slave
6ES7 315-2AF01-0AB0
Memory for user and basic
program
64, 96, 128 KB 64, 96 128, 160, 192, 224,
256, 288 KB
(dependent on option)
96, 160, 224, 288, 352, 416,
480 KB
(dependent on option)
Data block memory Like user memory Like user memory Up to 96 KB
Memory submodule no no no
Bit memories 2048 2048 2048/ 4096 with PLC
operating system 03.10.13 or
later
Timers 128 128 128
Counters 64 64 64
Clock memories 8 8 8
Program/data blocks
OB
FB
FC
DB
1, 10, 20, 35, 40,
80-82, 85, 87, 100,
121-122
1-127
1-127
1-127
1, 10, 20, 35, 40,
80-82, 85-87, 100,
121-122
1-127
1-127
1-127
1, 10, 20, 35, 40,
80-82, 85-87, 100,
121-122
0-255
0-255
1-399
Max. data block length 16 KB 16 KB 16 KB
Max. block length FC, FB 24 KB 24 KB 24 KB
Inputs/outputs
(address capacity)
- digital
- analog
768
64
1024/1024
64
1024/1024
64
