Detailed Description
2.11 General conditions and NC-VAR_Selector
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-69
Block size (bytes)
Block
type no.
Function
Remark
Working
memory
Maximum configuration (2 channels, 4 spindles, 4 axes, T MCP)
See above Basic program, base 5398
See above Interface DBs 2326
See above MCP 1328
See above Error/status
messages
1354
See above ASUBs 1 ASUB initiation 518
See above Concurrent axis For 2 turrets 882
See above PLC/NC
communication
1 x read variable and 1 x write variable 1240
See above Tool management 2 turrets with one loading point each 1940
See above Compile cycles 436
Total value 15422
2.11 2.11 General conditions and NC-VAR_Selector
2.11.1 Supplementary conditions
2.11.1.1 Programming and parameterizing tools
Hardware
Programming devices or PCs with the following equipment are required for the PLCs
installed on the 810D and 840D:
Minimum Recommendation
Processor Pentium Pentium
RAM (MB) 256 512 or more
Hard disk,
free capacity (MB)
500 > 500
Interfaces MPI, Ethernet incl. cable
Memory card
