Data Lists
5.2 Signals
Auxiliary Function Output to PLC (H2)
5-2 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Number Identifier: $MC_ Description
22210 AUXFU_S_SYNC_TYPE Output timing of S functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22230 AUXFU_H_SYNC_TYPE Output timing for H functions
22240 AUXFU_F_SYNC_TYPE Output timing of F functions
22250 AUXFU_D_SYNC_TYPE Output timing of D functions
22252 AUXFU_DL_SYNC_TYPE Output timing of DL functions
22254 AUXFU_ASSOC_M0_VALUE Additional M function for program stop
22256 AUXFU_ASSOC_M1_VALUE Additional M function for conditional stop
5.2 5.2 Signals
5.2.1 Signals to channel
DB number Byte.Bit Description
21, ... 30.5 Activate associated M01
5.2.2 Signals from channel
DB number Byte.Bit Description
21, ... 58.0 – 58.4 M function 1 - 5 change
21, ... 59.0 – 59.4 M function 1 - 5 not included in list
21, ... 60.0 - 60.2 S function 1 - 3 change
21, ... 60.4 - 60.6 S function 1 - 3 quick
21, ... 61.0 - 61.2 T function 1 - 3 change
21, ... 61.4 - 61.6 T function 1 - 3 quick
21, ... 62.0 - 62.2 D function 1 - 3 change
21, ... 62.4 - 62.6 D function 1 - 3 quick
21, ... 63.0 E function 1 change
21, ... 63.4 E function 1 quick
21, ... 64.0 - 64.2 H function 1 - 3 change
21, ... 64.4 - 64.6 H function 1 - 3 quick
21, ... 65.0 - 65.5 F function 1 - 6 change
