Data Lists
5.3 Signals
Axis Monitoring, Protection Zones (A3)
5-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5.3 5.3 Signals
5.3.1 Signals to channel
Axis monitoring functions
None
Protection zones
DB number Byte.Bit Description
21, ... 1.1 Enable protection zones
21, ... 4.7 Feed override
21, ... 6.0 Feed disable
21, ... 8.0 Activate machinerelated protection zone 1
: :
21, ... 8.7 Activate machinerelated protection zone 8
21, ... 9.0 Activate machinerelated protection zone 9
21, ... 9.1 Activate machinerelated protection zone 10
21, ... 10.0 Activate channelspecific protection zone 1
: :
21, ... 10.7 Activate channelspecific protection zone 8
21, ... 11.0 Activate channelspecific protection zone 9
21, ... 11.1 Activate channelspecific protection zone 10
5.3.2 Signals from channel
Axis monitoring functions
None
Protection zones
DB number Byte.Bit Description
21, ... 272.0 Machinerelated protection zone 1 preactivated
: :
21, ... 272.7 Machinerelated protection zone 8 preactivated
21, ... 273.0 Machinerelated protection zone 9 preactivated
