Auxiliary Function Output to PLC (H2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
1-1
Brief Description
1
1.1 1.1 Function
General
Auxiliary functions permit activation of NC system functions and PLC user functions.
Auxiliary functions can be programmed in part program blocks in the following:
• Part programs
• Synchronized actions
• User cycles
Detailed information on using auxiliary function output in synchronized actions is to be found
in:
References:
/FBSY/ Description of Functions Synchronized Actions
Predefined auxiliary functions
Predefined auxiliary functions activate system functions. The auxiliary function is also output
to the NC/PLC interface. The following auxiliary functions are predefined:
Type Function Example Meaning
M Miscellaneous (i.e.
special) function
M30 End of program
S Spindle function S100 Spindle speed 100, e.g. 1 rpm
T Tool number T3 Tool number 3
D, DL Tool offset D1 Tool cutting edge number 1
F Feed F1000 Feedrate 1000, e.g. mm/min
User-defined auxiliary functions
There are two uses for user-defined auxiliary functions:
• Extension of predefined auxiliary functions
• User-specific auxiliary functions
