Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
NC/PLC Interface Signals (Z1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-97
2.9.4 Signals from channel (DB21, ...)
DB21, ...
DBX32.3
Action block active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The action block is being executed.
Signal state 0 or
edge change
1 → 0
No action block active.
Additional references /BA/ Operator's Guide
DB21, ...
DBX32.5
M00/M01 active
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The part program block is processed, the auxiliary functions are output, and:
• M00 is in the RAM
• M01 is in the RAM and IS "Activate M01" is active
The program status changes to "Stopped".
Signal state 0 or
edge change
1 → 0
• With DB21, ... DBX7.1 (NC start)
• For a program abort as a result of a reset
