Detailed Description
2.10 Axis types, coordinate systems, frames (K2)
NC/PLC Interface Signals (Z1)
2-112 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB31, ...
DBX72.0
REPOSDELAY
Special cases,
errors, ......
The signal is not relevant for path axes.
Corresponds to .... DB21, ... DBX31.0 - DBX31.2 (REPOSPATHMODE)
DB31, ... DBX10.0 (REPOSDELAY)
DB31, ... DBX70.2 (REPOS Delay Ackn)
DB31, ...
DBX76.4
Path axis
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The axis is involved in the path (path axis).
Note
In conjunction with SERUPRO in status "Target block found", the signal refers to the status of the
axis in the target block.
Signal state 0 or
edge change
1 → 0
The axis is not involved in the path.
2.10 2.10 Axis types, coordinate systems, frames (K2)
2.10.1 Signals to axis/spindle (DB31, ...)
DB 31, ...
DBX3.0
External Zero Offset
Edge evaluation: no Signal(s) updated:
Signal state 1 or
edge change
0 → 1
The preselected value of the external work offeset of an axis is used as the new value for
calculating the total work offset between the basic and the workpiece coordinate systems.
Signal state 0 or
edge change
1 → 0
The preselected value of the external work offset of an axis is not used as the new value for
calculating the total work offset between the basic and workpiece coordinate systems. The previous
value is still valid.
Signal irrelevant
for ...
$AA_ETRANS[axis] equals zero for all axes.
Special cases,
errors, ......
Signal zero after ramp-up (power ON).
Corresponding to .... $AA_ETRANS[axis]
