5.3 Signals
Various NC/PLC Interface Signals and Functions (A2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-9
5.3.8 Signals from operator panel front
DB number Byte.Bit Description
19 20.1 Screen is dark
19 20.7 Switch over MCS/WCS
19 24.0 Error (Acknowledgment byte for current RS232 status)
19 24.1 O.K. (Acknowledgment byte for current RS232 status)
19 24.2 COM2 active (Acknowledgment byte for current RS232 status)
19 24.3 COM1 active (Acknowledgment byte for current RS232 status)
19 24.4 RS232 stop (Acknowledgment byte for current RS232 status)
19 24.5 RS232 External (Acknowledgment byte for current RS232C status)
19 24.6 RS232 OFF (Acknowledgment byte for current RS232 status)
19 24.7 RS232 ON (Acknowledgment byte for current RS232 status)
19 26.0 Error (Part program handling status)
19 26.1 O.K. (Part program handling status)
19 26.3 Active (Part program handling status)
19 26.5 Unload (Part program handling status)
19 26.6 Load (Part program handling status)
19 26.7 Select (Part program handling status)
19 42.0 FC9: Measure in JOG mode
19 45.0 FC9 Out: Active
19 45.1 FC9 Out: Done
19 45.2 FC9 Out: Error
19 45.3 FC9 Out: StartErr
