Page #521 background imageLoading...
Page #521 background image
Data Lists
5.2 Signals
Auxiliary Function Output to PLC (H2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-3
DB number Byte.Bit Description
21, ... 66.0 - 66.4 M function 1 - 5 quick
21, ... 67.0 - 67.5 F function 1 - 6 quick
21, ... 68 - 69 Extended address of M function 1 (binary)
21, ... 70 - 73 M function 1 (integer)
21, ... 74 - 75 Extended address of M function 2 (binary)
21, ... 76 - 79 M function 2 (integer)
21, ... 80 - 81 Extended address of M function 3 (binary)
21, ... 82 - 85 M function 3 (integer)
21, ... 86 - 87 Extended address of M function 4 (binary)
21, ... 88 - 91 M function 4 (integer)
21, ... 92 - 93 Extended address of M function 5 (binary)
21, ... 94 - 97 M function 5 (integer)
21, ... 98 - 99 Extended address of S function 1 (binary)
21, ... 100 - 103 S function 1 (real)
21, ... 104 - 105 Extended address of S function 2 (binary)
21, ... 106 - 109 S function 2 (real)
21, ... 110 - 111 Extended address of S function 3 (binary)
21, ... 112 - 115 S function 3 (real)
21, ... 116 - 117 Extended address of T function 1 (binary)
21, ... 118 - 119 T function 1 (integer)
21, ... 120 - 121 Extended address of T function 2 (binary)
21, ... 122 - 123 T function 2 (integer)
21, ... 124 - 125 Extended address of T function 3 (binary)
21, ... 126 - 127 T function 3 (integer)
21, ... 128 Extended address of D function 1 (binary)
21, ... 129 D function 1 (binary)
21, ... 130 Extended address of D function 2 (binary)
21, ... 131 D function 2 (binary)
21, ... 132 Extended address of D function 3 (binary)
21, ... 133 D function 3 (binary)
21, ... 134 Extended address of DL function (binary)
21, ... 136 DL function (real)
21, ... 140 - 141 Extended address of H function 1 (binary)
21, ... 142 - 145 H function 1 (real format)
21, ... 146 - 147 Extended address of H function 2 (binary)
21, ... 148 - 151 H function 2 (real or double integer)
21, ... 152 - 153 Extended address of H function 3 (binary)
21, ... 154 - 157 H function 3 (real format)
21, ... 158 - 159 Extended address of F function 1 (binary)
21, ... 160 - 163 F function 1 (real format)
21, ... 164 - 165 Extended address of F function 2 (binary)
21, ... 166 - 169 F function 2 (real format)
