Detailed Description
2.1 Key PLC CPU data for 810D, 840D and 840Di
PLC Basic Program Solution Line (P3 sl)
2-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
PLC versions
PLC 317-2DP with SIMATIC version 2.1.6 (version ID 20.70.24) or higher
is integrated. These versions are compatible with the corresponding SIMATIC CPU 300,
which means that all modules and software packages that are approved for these versions
and CPUs on SIMATIC are, therefore, suitable. Exceptions include modules that can usually
only be inserted in row 0 (other exceptions are the FMNC and FM 357 modules).
The version ID on the version screen comprises the following components:
• SIMATIC CPU PLC primary version identifier
• Firmware transfer increment
• Internal increment
Example ID
317-2DP PLC with MLFB 6FC5 317-2AJ10-0AB0: 20.70.24
Version screen on HMI
The PLC currently being used and the associated version of the PLC operating system are
displayed under PLC on the version screen,
for example
PLC_317-2DP 20.70.24
The module code of the PLC module used appears in the preceding column. The following
PLC module codes are currently in use:
Module code PLC module Suitable PLC operating
systems (corresponding
SIMATIC MLFB)
Operating system
SW version ID
2000 PLC 317-2DP with
IBC32
6ES7 317-2AJ10-0AB0,
FW 2.1
20.70.24
MCI 2 (840Di)
2100
PLC 317-2DP with
IBC32
6ES7 317-2AJ10-0AB0,
FW 2.1
20.70.24
