Detailed Description
2.11 General conditions and NC-VAR_Selector
PLC Basic Program Solution Line (P3 sl)
2-82 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Delete variables
Variables are deleted in the window of selected variables by selecting the appropriate
variables (single mouse click) and pressing the "Delete" key. No deletion action is taken with
the double-click function. It is possible to select several variables for deletion (see "Selecting
variables").
This action can also be undone under the "Edit" menu item.
Note
Deleting of variables results in a change of the absolute addresses of the pointer structures
to the variables. When changing the variable selection, it is, therefore, absolutely necessary
to generate one or several text files of all user blocksprior to the change. This is the only way
to ensure that the assignment of the variables in FB "GET" or FB "PUT" remains correct,
even after recompilation.
Storing a selected list
Once variables have been selected, they can be stored under a project name. The files are
stored on a project-specific basis.
A window is displayed for the file to be stored. The project path and name for the file must be
selected in the window.
Fig. 2-29 Window for project path and name of file to be stored
