Examples
4.1 Definition and activation of protection zones
Axis Monitoring, Protection Zones (A3)
4-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
$SN_PA_CONT_ORD[0,
0]
-100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 0
$SN_PA_CONT_ORD[0,
1]
-100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 1
$SN_PA_CONT_ORD[0,
2]
100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 2
$SN_PA_CONT_ORD[0,
3]
100 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 3
$SN_PA_CONT_ORD[0,
4]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 4
$SN_PA_CONT_ORD[0,
5]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 5
$SN_PA_CONT_ORD[0,
6]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 6
$SN_PA_CONT_ORD[0,
7]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 7
$SN_PA_CONT_ORD[0,
8]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 8
$SN_PA_CONT_ORD[0,
9]
0 ; Endpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 9
$SN_PA_CONT_ABS[0,
0]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 0
$SN_PA_CONT_ABS[0,
1]
110 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 1
$SN_PA_CONT_ABS[0,
2]
110 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 2
$SN_PA_CONT_ABS[0,
3]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 3
$SN_PA_CONT_ABS[0,
4]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 4
$SN_PA_CONT_ABS[0,
5]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 5
$SN_PA_CONT_ABS[0,
6]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 6
$SN_PA_CONT_ABS[0,
7]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 7
$SN_PA_CONT_ABS[0,
8]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 8
$SN_PA_CONT_ABS[0,
9]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for spindle chuck, contour element 9
$SN_PA_CENT_ORD[0,
0]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 0
$SN_PA_CENT_ORD[0.
1]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 1
$SN_PA_CENT_ORD[0.
2]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 2
$SN_PA_CENT_ORD[0.
3]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for spindle chuck, contour element 3
