Examples
4.1 Definition and activation of protection zones
Axis Monitoring, Protection Zones (A3)
4-6 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
$SC_PA_LIM_3DIM[1] 0 ; Type of limitation in the third dimension: 0 = no limitation
; Protection zone for tool holder
$SC_PA_PLUS_LIM[0] 0 ; Value of limitation in positive direction in the third dimension
; Protection zone for workpiece
$SC_PA_PLUS_LIM[1] 0 ; Value of limitation in positive direction in the third dimension
; Protection zone for tool holder
$SC_PA_MINUS_LIM[0] 0 ; Value of limitation in negative direction in the third dimension
; Protection zone for workpiece
$SC_PA_MINUS_LIM[1] 0 ; Value of limitation in negative direction in the third dimension
; Protection zone for tool holder
$SC_PA_CONT_NUM[0] 4 ; Number of valid contour elements,
; Protection zone for workpiece
$SC_PA_CONT_NUM[1] 5 ; Number of valid contour elements,
; Protection zone for tool holder 1
$SN_PA_CONT_TYP[0,
0]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 0
$SN_PA_CONT_TYP[0,
1]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_TYP[0,
2]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_TYP[0,
3]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_TYP[0,
4]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_TYP[0,
5]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_TYP[0,
6]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_TYP[0,
7]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_TYP[0,
8]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_TYP[0,
9]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_TYP[1,
0]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_TYP[1,
1]
3 ; Contour type[i] : 3 = G3 f. Circuit element, counter-clockwise,
; Protection zone for tool holder, contour element 1
$SN_PA_CONT_TYP[1,
2]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_TYP[1,
3]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_TYP[1,
4]
1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 4
$SN_PA_CONT_TYP[1,
5]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 5
$SN_PA_CONT_TYP[1,
6]
0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 6
