Examples
4.1 Definition and activation of protection zones
Axis Monitoring, Protection Zones (A3)
4-8 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
$SN_PA_CONT_ABS[0,
1]
40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_ABS[0,
2]
40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_ABS[0,
3]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_ABS[0,
4]
-50 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_ABS[0,
5]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_ABS[0,
6]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_ABS[0,
7]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_ABS[0,
8]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_ABS[0,
9]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_ABS[1,
0]
-50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_ABS[1,
1]
-30 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 1
$SN_PA_CONT_ABS[1,
2]
20 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_ABS[1,
3]
50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_ABS[1,
4]
-50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 4
$SN_PA_CONT_ABS[1,
5]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 5
$SN_PA_CONT_ABS[1,
6]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 6
$SN_PA_CONT_ABS[1,
7]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 7
$SN_PA_CONT_ABS[1,
8]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 8
$SN_PA_CONT_ABS[1,
9]
0 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 9
$SN_PA_CENT_ORD[0,
0]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 0
$SN_PA_CENT_ORD[0.
1]
-190 ; Midpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 1
$SN_PA_CENT_ORD[0.
2]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 2
$SN_PA_CENT_ORD[0.
3]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 3
$SN_PA_CENT_ORD[0.
4]
0 ; Midpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 4
