2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-137
The search area can be predefined in the following way by setting parameters
MagazineNumber_From, LocationNumber_From, MagazineNumber_To,
LocationNumber_To:
Magazine
Number
_From
Location
Number
_From
Magazine
Number_To
Location
Number_To
Search area
WVar1 WVar2 WVar3 WVar4
#M1 #P1 #M1 #P1 Only location #P1 in magazine #M1 is
checked
#M1 #P1 #M2 #P2 Locations starting at magazine #M1, location
#P1 up to magazine #M2, location #P2 are
searched
#M1 -1 #M1 -1 All locations in magazine #M1 - and no others
- are searched
#M1 -1 -1 -1 All locations starting at magazine #M1 are
searched
#M1 #P1 -1 -1 All locations starting at magazine #M1 and
location #P1 are searched
#M1 #P1 #M1 -1 Locations in magazine #M1 starting at
magazine #M1 and location #P1 in this
magazine are searched
#M1 #P1 #M2 -1 Locations starting at magazine #M1, location
#P1 up to magazine #M2, location #P2 are
searched
#M1 -1 #M2 #P2 Locations starting at magazine #M1 up to
magazine #M2, location #P2 are searched
#M1 -1 #M2 -1 Locations starting at magazine #M1 up to and
including magazine #M2 are searched
-1 -1 -1 -1 All magazine locations are searched
Note
Before and after this PI service, the MMCSEM PI service must be called up with the
associated parameter WVar1 for this PI service. See PI service MMCSEM for more
information.
