Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-191
Pulse diagram
6WDUW(UU
(UURU
6WDUW
,Q3RV
(1) Activation of function by means of a positive signal edge with start or stop
(2) Positive acknowledgment: Function executed/position reached
(3) Reset function activation after receipt of acknowledgment
(4) Signal change using FC
Timing diagram (fault scenario)
6WDUW(UU
(UURU
6WDUW
,Q3RV
(1) Activation of function by means of a positive signal edge with start or stop
(2) Negative acknowledgment: Error has occurred
(3) Reset function activation after receipt of acknowledgment
(4) Signal change using FC
