Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-197
MCP selection signals to the user interface
Keylock switch
Source:
MCP switch
Destination:
Interface DB
Position 0 DB10.DBX56.4
Position 1 DB10.DBX56.5
Position 2 DB10.DBX56.6
Position 3 DB10.DBX56.7
Operating modes and machine functions
Source:
MCP button
Destination:
Interface DB (parameter ChanNo)
AUTOMATIC DB11, ... DBX0.0
MDI DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. DB11.DBB2, Bits 0 to 5
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The associated interface bits are deleted
for axes, which are not selected.
Source:
MCP button
Destination:
Interface DB (parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
