Detailed Description
2.12 Block descriptions
PLC Basic Program Solution Line (P3 sl)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-199
Checkback signals from user interface for controlling displays
Operating modes and machine functions
Destination:
MCP LED
Source:
Interface DB (parameter ModeGroupNo)
AUTOMATIC DB11, ... DBX6.0
MDI DB11, ... DBX6.1
JOG DB11, ... DBX6.2
REPOS DB11, ... DBX7.1
REF DB11, ... DBX7.2
TEACH IN DB11, ... DBX7.0
Destination:
MCP LED
Source:
Interface DB (parameter ModeGroupNo)
INC 1 ... 10 000, INC Var. DB11.DBB8, bits 0 to 5
Channel signals
Destination:
MCP LED
Source:
Interface DB (parameter ChanNo)
NC Start DB21, ... DBX35.0
NC Stop DB21, ... DBX35.2 or DB21, ... DBX35.3
Single block DB21, ... DBX0.4
Note
Direction-key LEDs are activated by pressing the direction keys.
Axis selection and WCS/MCS LEDs are activated by pressing the relevant pushbutton
switch.
