Detailed Description
2.1 Spindle modes
Spindles (S1)
2-24 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
• The dynamic limits of the axis stored in the machine data are applicable in axis operation.
• The axis switches to the current feedforward control mode as designated by the MD and
the commands FFWON and FFWOF.
For more information about the servo parameter set, please refer to:
References:
/FB1/ Descriptions of Functions, Basic Machine; Velocities, Setpoint/Actual-Value
Systems, Closed-Loop Control (G2)
• When using resolution changes in (analog) drive actuators, the following NC program
steps are required:
Table 2-1 Change over to axis mode:
SPOS=...
M5 Closed-loop controller enable off (by PLC)
→ Output to PLC
M70 Switch actuator (by PLC on account of M70)
Closed-loop controller enable on (by PLC)
C=... NC travels with axis parameter set
Table 2-2 Switch back to spindle mode
C=...
M71 → Output to PLC
Closed-loop controller enable off (by PLC)
Switch actuator (by PLC)
Switched to spindle parameter set (1-5) internally in the NC,
controller enable on (by PLC)
M3/4/5
or
SPOS=...
NC travels with spindle parameter set
