Detailed Description
2.4 Selectable spindles
Spindles (S1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-59
Spindle number converter
MD20092 $MC_SPIND_ASSIGN_TAB_ENABLE = 1 Activate spindle number converter
SD42800 $SC_SPIND_ASSIGN_TAB[0] = 1 Master spindle as configured
SD42800 $SC_SPIND_ASSIGN_TAB[1] = 1 Basic table setting
SD42800 $SC_SPIND_ASSIGN_TAB[2] = 2
SD42800 $SC_SPIND_ASSIGN_TAB[3] = 3
SD42800 $SC_SPIND_ASSIGN_TAB[4] = 0 Logical spindle not assigned
M3 S1000 Address extension = 1, M1=3 S1=1000 is output. The spindle with the
configured No. "1" (No. of physical master spindle) rotates.
...
...
SD42800 $SC_SPIND_ASSIGN_TAB[1] = 5 Assignment of logical spindle 1 to
physical spindle 5
SD42800 $SC_SPIND_ASSIGN_TAB[2] = 3 Assignment of logical spindle 2 to
physical spindle 3.
Caution: physical spindle 3 has now been
assigned twice. When programming logical
spindles 2 and 3, physical spindle 3 is
always addressed. In the basic machine
displays, both spindles rotate.
SETMS (2) SD42800 $SC_SPIND_ASSIGN_TAB[0] = 2 defined internally by NCK.
...
M5 Master spindle = address extension = 2, spindle number M3=5
The physical spindle configured with number "3" stops.
...
GET (S4) Alarm 16105, as logical spindle "4" cannot be switched.
...
RELEASE (S1) Channel spindle "1" = physical. Spindle "5" is enabled.
...
M30
