Detailed Description
2.3 Feedrate control
Feeds (V1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-49
• When the operating mode is changed from AUTO ⇒ JOG, the programmed dynamic
response changes remain valid.
• In the event of a RESET, the last programmed value remains for the part program
specifications. The settings for main-run interpolations do not change.
• Block search:
The last end-of-motion criterion programmed for an axis is collected and output in an
action block. The last block with a programmed end-of-motion criterion that was
processed in the search run serves as a container for all programmed end-of-motion
criteria for all axes.
Example:
N01 G01 POS[X]=20 POS[Y]=30 IPOENDA[X] IPOENDA[Y]
N02 POS[Z]=55 FINEA[Z]
N03 $A_OUT[1]=1
N04 POS[X]=100 COARSEA[X]
N05 ......
TARGET: ; Block search target
• In this example, N04 serves as a container for all programmed end-of-motion criteria.
Two action blocks are saved. The digital output (N03) is issued in the first action block
and in the second, COARSEA is set for the X axis, IPOENDA for the Y axis and FINEA for
the Z axis.
The same applies to the programmed servo parameter set. The last programmed
acceleration override is effective from the first approach block.
