Detailed Description

2.9 Sum offsets and setup offsets

Tool Compensation (W1)

2-132 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0

Note

DL0 is not allowed. If compensation is deselected (D0 and T0), the sum offset also becomes

ineffective.

Programming a sum offset that does not exist triggers an alarm, similar to programming a

D compensation that does not exist.

Thus, only the defined wear remains part of the compensation (defined in system variables

$TC_DP12 to $TC_DP20).

Programming a sum offset when a D compensation is active (also applies to deselection)

has the same effect on the path as programming a D command. An active radius

compensation will, therefore, lose its reference to adjacent blocks.

Configuration

MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4=0: Default setting:

Only one set of sum offsets exists per DL number.

We refer in general to the sum offset.

This describes the data represented by $TC_SCPx.

'RIIVHW

6XPRIIVHW

6XPRIIVHW

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@

Fig. 2-49 MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4 = 0
