Examples
4.1 Toolholder with orientation capability
Tool Compensation (W1)
4-6 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
N10 $TC_TP2[1] = "MillingTool" ; Name of identifier
N20 $TC_TP7[1]=9 ; Location types
N30 $TC_TP8[1]=2 ; Status: enabled and not blocked
; D corr. D=1
N40 $TC_DP1[1,1]=120 ; Tool type - milling
N50 $TC_DP3[1,1]=; tool length compensation
vector
N60 $TC_DP12[1,1]= ; wear
N70 $TC_SCP13[1,1]=0.1 ; Sum offset DL=1
N80 $TC_ECP13[1,1]=0.01 ; Insert offset DL=1
N90 $TC_ADPTT[1]=5 ; Adapter transformation
N100 $TC_ADPT1[1]=0.001 ; Adapter dimension
; Magazine data
N110 $TC_MAP1[1]=3 ; Magazine type: Revolver
N120 $TC_MAP2[1]="Revolver" ; Magazine identifier
N130 $TC_MAP3[1]=17 ; Status of magazine
N140 $TC_MAP6[1]=1 ; Dimension - line
N150 $TC_MAP7[1]=2 ; Dimension - column -> 2 positions
N160 $TC_MPP1[1,1]=1 ; Location type
N170 $TC_MPP2[1,1]=9 ; Location types
N180 $TC_MPP4[1,1]=2 ; Location state
N190 $TC_MPP7[1,1]=1 ; Bring adapter into position
N200 $TC_MPP6[1,1]=1 ; T number "MillingTool"
N210 $TC_MAP1[9999]=7 ; Magazine type: buffer
N220 $TC_MAP2[9999]="buffer" ; Magazine identifier
N230 $TC_MAP3[9999]=17 ; Status of magazine
N240 $TC_MAP6[9999]=1 ; Dimension - line
N250 $TC_MAP7[9999]=1 ; Dimension - column -> 1 position
N260 $TC_MPP1[9999.1]=2 ; Location type
N270 $TC_MPP2[9999.1]=9 ; Location types
N280 $TC_MPP4[9999.1]=2 ; Location state
N290 $TC_MPP5[9999,1]=1 ; Spindle no. 1
N300 $TC_MDP2[1,1]=0 ; Distance from spindle to mag. 1
; Definition of toolholder 1
N310 $TC_CARR10[1] = 1 ; Component of 2nd rotary axis in X
direction
N320 $TC_CARR14[1] = 45 ; Angle of rotation of 2nd axis
N330 $TC_CARR23[1] = "T" ; Tool mode
N340 Stopre
N350 $SC_WEAR_TRANSFORM = 'B101'
