Detailed Description
2.1 Various interface signals and functions (A2)
NC/PLC Interface Signals (Z1)
2-48 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
DB31, ...
DBX92.3
Speed setpoint smoothing active
Corresponding to .... DB31, ... DBX20.3 (speed setpoint smoothing)
Additional references /IAD/ SINUMERIK 840D Installation and Startup Guide; Chapter: SIMODRIVE 611D
DB31, ...
DBX93.0 - DBX93.2
Active drive parameter set A, B, C
Edge evaluation: no Signal(s) updated: cyclic
Meaning The drive module (611D/611U) signals back to the PLC which drive parameter set is currently
active.
With bit combinations A, B and C, 8 different drive parameter sets can be selected for the 611D.
The following assignment applies:
$FWLYHGULYHSDUDPHWHUVHW
&
%
$
Application
example(s)
Drive parameter switchover can be used for the following:
• To change the gear stage
• To change over the measuring circuit
Corresponding to .... DB31, ... DBX21.0 - DBX21.2 (drive parameter set selection)
Additional references DB31, ... DBX21.0 - DBX21.2 (drive parameter set selection)
or
/IAD/ SINUMERIK 840D Installation and Start-up Guide; Chapter: SIMODRIVE 611D
or
/IAG/ SINUMERIK 810D Installation and Start-up Guide
