Detailed Description
2.4 Drive service display (for digital drives only)
Diagnostic Tools (D1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-15
Note
The parameters in the "Drive" service display are not necessary for connecting drives via the
PROFIBUS DP. For SINUMERIK 840Di, the drives are defined as PROFIBUS nodes. The
appropriate service data is displayed in 840DiStartup in the menu Diagnostics -->
PROFIBUS.
Application
The diagnostic options are used for:
• Checking the status of enabling and control signals
(e.g. pulse enable, drive enable, motor selection, setpoint parameter set)
• Checking the status of FDD/MSD operating modes
(e.g. setup mode, parking axis)
• Displaying temperature warnings
• Checking the current setpoint/actual value display
(e.g. actual position value measuring system 1/2, speed setpoint, actual speed value)
• Checking the drive status (drive ready)
• Displaying the current ramp-up phase
• Displaying the group error message (message status class 1)
• Displaying the drive status messages
(e.g. threshold torque not reached, minimum speed not reached, actual speed = set
speed)
Service HMI Advanced Drive
Descriptions on how to select and operate the "Diagnostics" area can be found in
References: /BAD/, "HMI Advanced Operator's Guide"
/BEM/, "HMI Embedded Operator's Guide"
Note
The individual status displays, warnings, messages, etc., are explained in the following
sections. For HMI SW 6 and higher, the status is shown in plain text as "yes" or "no" instead
of "0" and "1".
For additional information, see:
References: /IAD/, "Installation and Start-Up Guide"
