Data Lists
5.1 Machine data
Velocities, Setpoint/Actual-Value Systems, Closed-Loop Control (G2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
5-3
Number Identifier: $MA_ Description
31040 ENC_IS_DIRECT[n] Encoder is connected directly to the machine
31044 ENC_IS_DIRECT2 Encoder on intermediate gear
31050 DRIVE_AX_RATIO_DENOM[n] Denominator load gearbox
31060 DRIVE_AX_RATIO_NUMERA[n] Numerator load gearbox
31064 DRIVE_AX_RATIO2_DENOM Intermediate gear denominator
31066 DRIVE_AX_RATIO2_NUMERA Intermediate gear numerator
31070 DRIVE_ENC_RATIO_DENOM[n] Measuring gear denominator
31080 DRIVE_ENC_RATIO_NUMERA[n] Measuring gear numerator
31090 JOG_INCR_WEIGHT Weighting of increment for INC/handwheel
31200 SCALING_FACTOR_G70_G71 Factor for converting values when G70/G71 is active
32000 MAX_AX_VELO Maximum axis velocity
32100 AX_MOTION_DIR Travel direction
32110 ENC_FEEDBACK_POL[n] Sign actual value (feedback polarity)
32200 POSCTRL_GAIN [n] Servo gain factor (Kv)
32210 POSCTRL_INTEGR_TIME Integrator time position controller
32220 POSCTRL_INTEGR_ENABLE Activation of integral component of position controller
32250 RATED_OUTVAL[n] Rated output voltage
32260 RATED_VELO[n] Rated motor speed
32450 BACKLASH[n] Backlash
32500 FRICT_COMP_ENABLE Friction compensation active
32610 VELO_FFW_WEIGHT Feedforward control factor for speed feedforw. control
32620 FFW_MODE Feedforward control mode
32630 FFW_ACTIVATION_MODE Activate feedforward control from program
32650 AX_INERTIA Moment of inertia for torque feedforward control
32711 CEC_SCALING_SYSTEM_METRIC System of measurement of sag compensation
32800 EQUIV_CURRCTRL_TIME [n] Equivalent time constant current control loop for
feedforward control
32810 EQUIV_SPEEDCTRL_TIME [n] Equivalent time constant speed control loop for
feedforward control
32900 DYN_MATCH_ENABLE Dynamics matching
32910 DYN_MATCH_TIME [n] Time constant for dynamic response adaptation
32930 POSCTRL_OUT_FILTER_ENABLE Activ. of low-pass filter at position controller output
32940 POSCTRL_OUT_FILTER_TIME Time constant of low-pass filter at positon controller
output
32950 POSCTRL_DAMPING Factor for additional damping of position control loop
32960 POSCTRL_ZERO_ZONE[n] Dead zone position controller
33000 FIPO_TYPE Fine interpolator type
34320 ENC_INVERS[n] Length measuring system is inverse
35100 SPIND_VELO_LIMIT Maximum spindle speed
36200 AX_VELO_LIMIT [n] Threshold value for velocity monitoring
36210 CTRLOUT_LIMIT[n] Maximum speed setpoint
36400 AX_JERK_ENABLE Axial jerk limitation
36410 AX_JERK_TIME Time constant for axial jerk filter
