Brief Description
1.2 Overview of auxiliary functions
Auxiliary Function Output to PLC (H2)
1-4 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
• M-function-specific machine data:
– MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN
– MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
– MD10804 $MN_EXTERN_M_NO_SET_INT
– MD10806 $MN_EXTERN_M_NO_DISABLE_INT
– MD10814 $MN_EXTERN_M_NO_MAC_CYCLE
– MD10815 $MN_EXTERN_M_NO_MAC_CYCLE_NAME
– MD20094 $MC_SPIND_RIGID_TAPPING_M_NR
– MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
– MD20096 $MC_T_M_ADDRESS_EXT_IS_SPINO
– MD22200 $MC_AUXFU_M_SYNC_TYPE
– MD22530 $MC_TOCARR_CHANGE_M_CODE
– MD22532 $MC_GEOAX_CHANGE_M_CODE
– MD22534 $MC_TRAFO_CHANGE_M_CODE
– MD22560 $MC_TOOL_CHANGE_M_CODE
S functions
S (spindle function)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
0 - 12 Spindle number
5)
0 - +/-3.4028 ex 38
3)
REAL Spindle speed 3
Remarks:
The master spindle of the channel is addressed if no address extension is specified.
Application
Spindle speed.
Remarks
• S functions are assigned to auxiliary function group 3 by default.
• Without an address extension, the S functions refer to the master spindle of the channel.
• S-function-specific machine data:
– MD22210 $MC_AUXFU_S_SYNC_TYPE
