2.2 User-defined auxiliary functions
Auxiliary Function Output to PLC (H2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-13
Type
Address extension
1)
System function
Value
Tool change M 1 6
Spindle right M 1 3
Spindle left M 1 4
Spindle stop M 1 5
Position spindle M 1 19
Axis mode M 1 70
Automatic gear stage M 1 40
Gear stage 1 M 1 41
Gear stage 2 M 1 42
Gear stage 3 M 1 43
Gear stage 4 M 1 44
Gear stage 5 M 1 45
Spindle speed S 1 -1
Tool selection T 1 -1
1) address extension = 1 is the default value used in the auxiliary functions predefined in the machine
data.
Example
Extension of the predefined auxiliary function for the system function: "Spindle right" for the
2nd and 3rd spindle of the channel.
Auxiliary function "Spindle right" for the 2nd spindle of the channel
MD22010 $MC_AUXFU_ASSIGN_TYPE[ n ] = "M"
MD22020 $MC_AUXFU_ASSIGN_EXTENSION[ n ] = 2
MD22030 $MC_AUXFU_ ASSIGN_VALUE[ n ] = 3
Auxiliary function "Spindle right" for the 3rd spindle of the channel
MD22010 $MC_AUXFU_ ASSIGN_TYPE[ m ] = "M"
MD22020 $MC_AUXFU_ASSIGN_EXTENSION[ m ] = 3
MD22030 $MC_AUXFU_ ASSIGN_VALUE[ m ] = 3
