Detailed Description
2.2 User-defined auxiliary functions
Auxiliary Function Output to PLC (H2)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-17
Parameterization: M4
• Machine data index: 1 (2. user-defined auxiliary function)
• Auxiliary function group: 5
• Type and value: M4 (spindle left)
• Address extension: 2 as appropriate for the 2nd spindle of the channel
• Output behavior:
– Output duration one OB1 cycle (normal acknowledgment)
– Spindle response following acknowledgment
– Output during motion
Machine data Machine data index Value
MD22000 $MC_AUXFU_ASSIGN_GROUP 1 5
MD22010 $MC_AUXFU_ASSIGN_TYPE 1 'M'
MD22020 $MC_AUXFU_ASSIGN_EXTENSION 1 2
MD22030 $MC_AUXFU_ASSIGN_VALUE 1 4
MD22035 $MC_AUXFU_ASSIGN_SPEC 1 H51
Parameterization: M5
• Machine data index: 2 (3. user-defined auxiliary function)
• Auxiliary function group: 5
• Type and value: M5 (spindle stop)
• Address extension: 2 as appropriate for the 2nd spindle of the channel
• Output behavior:
– Output duration one OB1 cycle (normal acknowledgment)
– Spindle response following acknowledgment
– Output at block end
