Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-85
Program statuses
The following program states are available:
• Interface signal DB21, ... DBX35.4 ("Program status aborted")
• Interface signal DB21, ... DBX35.3 ("Program status interrupted")
• Interface signal DB21, ... DBX35.2 ("Program status stopped")
• Interface signal DB21, ... DBX35.1 ("Program status waiting")
• Interface signal DB21, ... DBX35.0 ("Program status running")
For a further explanation of the individual signals, refer to the data lists.
The effect of commands/signals
The program status can be controlled by activating different commands or interface signals.
The following table shows the resulting program status when these signals are set
(assumption: status before the signal is set -> Program status running).
Table 2-2 Effect on program status
Commands
Program execution statuses
Aborted Interrupted Stopped Wait Running
IS "Reset" X
IS "NC Stop" X
IS "NC stop at block limit" X
IS "NC stop axes and spindles" X
IS "Read-in disable" X
IS "Feed stop, channelsp." X
IS "Feed stop, axissp." X
Feed override = 0% X
IS "Spindle stop" X
M02/M30 in a block X
M00/M01 in a block X
IS "Single block" X
IS "Delete distancetogo" X
Auxiliary functions output to PLC but
not yet acknowledged
X
Wait instruction in program X
