Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
2-94 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Event
Power-up
Table 2-8 Table 1–9 Sequence during power-up
Sequence Command Boundary conditions
(must be satisfied before the
command)
Comments
1 Reset after power up
2 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152 $MC_
GCODE_RESET_MODE
Control activated:
After power-up:
Reset sequence with evaluation
After power-up, control enables
the reset sequence with
evaluation of MD 20110 and MD
20150 and MD 20152
3 /_N_CMA_DIR/_N_PROG_
EVENT_SPF or name from
MD11620
As an ASUB Implied call of the path name as
an ASUB
4 MD20110 $MC_
RESET_MODE_MASK,
MD20150 $MC_
GCODE_RESET_VALUES,
MD20152 $MC_
GCODE_RESET_MODE
Control activated:
Reset sequence with evaluation
Control activated
Reset sequence with evaluation
of MD20110 and MD20150 and
MD20152. Meaning:
The G-code indexed position
continues to be specified with
machine data
Chronological sequences
For part program start and part-program end:
Time sequence of VDI signals DB21-DB30, ... DBB35 ("Program status" and "Channel
status") when processing a part program with an event-driven program call for part program
start and part program end:
