Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-99
Example for call of operator panel reset
For MD20108 $MC_PROG_EVENT = 'H04'
PROC PROG_EVENT DISPLOF
N10 DRFOF ; Deactivate DRF offsets
N20 M17
Start with RESET key
Control with MD PROG_EVENT_IGN_INHIBIT
The part program whose name is in MD11620 $MN_PROG_EVENT_NAME and which was
stored in one of the directories /_N_CUS_DIR/, /_N_CMA_DIR/, or /_N_CST_DIR/ or the
_N_PROG_ENENT_SPF program (default) is automatically started with the RESET key and
executed up to the end, regardless of any read-in disable, if the following MD settings are
present:
CHANDAT(3)
$MC_PROG_EVENT_IGN_INHIBIT= 'H04F'
$MC_PROG_EVENT_MASK= 'H04F'
Note
For block search (SSL):
If MD11450 $MN_SEARCH_RUN_MODE Bit 1 = TRUE, activation of the last action block
also implicitly activates "Automatic ASUB start" after block search of
/_N_CMA_DIR/_N_PROG_EVENT_SPF.
For further explanation, refer to "Automatic start of an ASUB after block search" in the
"Program Test" section.
For further explanation of power-up of the control, see
References: /IAD/, "Power-On and Power-Up"
