Detailed Description
2.7 Program operation mode
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-113
Installation of user system ASUBs
One routine named _N_ASUP_SPF can be loaded in directory _N_CUS_DIR. It must
implement the actions desired by the user for:
RET on value 1 in MD11610
REPOS on value 2 in MD11610.
$AC_ASUP
Bit 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RET 1 1 * 1
REPOS 1 1 1 1 1 1 1 1 * 1 1 1
*) If Bit 9 is set, then the branch is determined by MD20114: MODESWITCH_MASK starting
with:
Bit 0 is set in MD 20114: →RET
Bit 0 in MD20114 not set: →REPOS
Meaning of bits
The meaning of the bits of system variable $AC_ASUP is as follows:
Bit Meaning
0 User interrupt "ASUB with Blsync"
Continuation: Freely selectable REORG or RET
1 User interrupt "ASUB"; The position at which the routine was stopped is stored for
continuation with REPOS.
Continuation: Freely selectable REORG or RET
2 User interrupt "ASUB from channel status Ready"
Continuation: Freely selectable REORG or RET
3 User interrupt "ASUB in a manual mode and in channel status Not
Ready".
Continuation: Freely selectable REORG or RET
4 User interrupt "ASUB"; The current position as the interrupt occurred is stored for
continuation with REPOS.
Continuation: Freely selectable REORG or RET
5 Abortion of subroutine repeat
Continuation: With system ASUB REPOS
6 Activation of decoder single block
Continuation: With system ASUB REPOS
7 Activation of delete distance-to-go
Continuation: With system ASUB RET
8 Activation of axis synchronization
Continuation: With system ASUB REPOS
9 Operating mode switchover
Continuation: On system ASUB REPOS or RET depending on MD11610
