Detailed Description
2.10 System settings for power-up, RESET/part-program end and part-program start
Mode Group, Channel, Program Operation, Reset Response (K1)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-139
Table 2-13 Effect of MD20110 $MC_RESET_MODE_MASK Bits 0 to 6
Bit 0 = 1 Bit 1 = 1 Bit 2 = 1 Bit 3 = 1 Bit 4 = 1 Bit 5 = 1 Bit 6 = 1
Initial setting
after power
up and
RESET/end
of part
program
see above
No D, T, M
output on
tool
selection;
with active
tool
manage-
ment
irrelevant
If bit 0=1 and bit 6
=1, the tool offset
of the last active
tool is active after
POWER ON
(irrelevant with
active tool
management)
Use active
tool or tool
offset from
last test
program
terminated in
test mode
Current
plane is
retained, in
SW 5
replaced by
MD 20152
index 5
see below
Current
settable
frame is
retained, as
of SW 5
replaced by
MD 20152
index 7
see below
Active
tool offset is retained
Bit 0 = 0 Bit 1 = 0 Bit 2 = 0 Bit 3 = 0 Bit 4 = 0 Bit 5 = 0 Bit 6 = 0
Initial setting
after power
up and
RESET/end
of part
program
see above.
D, T, M
output on
tool
selection;
with active
tool
management
irrelevant.
No tool offset
active after
POWER ON
(no effect when
tool management
active).
Use active
tool or tool
offset from
last program
terminated
before
program
testing
activated.
Plane
according to
MD20150
$MC_
GCODE_
RESET_
VALUES; in
SW 5 and
higher,
replaced by
MD 20152
index 5
see below.
Frame
according to
MD20150
$MC_
GCODE_
RESET_
VALUES; in
SW 5 and
higher,
replaced by
MD 20152
index 7
see below.
WZK according to
MD20120
$MC_TOOL_RESET_
VALUE, MD20121
$MC_TOOL_PRESEL_
RESET_VALUE,
MD20130
$MC_CUTTING_
EDGE_RESET_VALUE;
Output of D, T, M to PLC,
depending on bit 1.
Table 2-14 Effect of MD20110 $MC_RESET_MODE_MASK Bits 7 to 12
Bit 7 = 1 Bit 8 = 1 Bit 9 = 1 Bit 10 = 1 Bit 11 = 1 Bit 12 = 1
Active trans-
formation
is retained.
Coupledaxis
groupings are
retained.
Tangential
follow-up is
retained.
Not configured
synchronous
spindle coupling
remains active.
Current setting
for revolutional
feedrate is
retained.
Modified geometry axis
assignment is retained.
Bit 7 = 0 Bit 8 = 0 Bit 9 = 0 Bit 10 = 0 Bit11 = 0 Bit 12 = 0
Transformation
according to
MD20140
$MC_TRAFO_
RESET_
VALUE.
Coupledmotion
groupings are
deactivated.
Tangential
follow-up is
deactivated.
Not configured
synchronous
spindle coupling
is switched off.
Revolutional
feedrate is no
longer valid.
Modified geometry axis
assignment is deleted
according to
MD 20050, depending on
MD20118 (because of
compatibility).
