2.11 Subroutine call with M, T, and D functions
Mode Group, Channel, Program Operation, Reset Response (K1)
2-156 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
Conflict resolution in case of multiple replacements with the same name
The following table provides information on how conflicts are resolved if all three
replacement subroutines have been configured with different names.
Replacement Configuration of replacement subroutines
For Address D and DL: MD11717 $MN_FCT_CYCLE_NAME = "D_SUB_PROG"
For Address T: MD10717 $MN_FCT_CYCLE_NAME = "T_SUB_PROG"
For the call of the tool change program
MD10716 $MN_M_NO_FCT_CYCLE_NAME[0] = "M6_SUB_PROG"
MD10715 $MN_M_NO_FCT_CYCLE[0] = 6
For M function
MD10718 $MN_M_NO_FCT_CYCLE_PAR = 0
Parameterization MD22550 $MC_TOOL_CHANGE_MODE = 1
MD22560 $MC_TOOL_CHANGE_M_CODE = 206
The following are programmed in one part
program line
Called replacement subroutine
D and/or DL T M6
– – X M6_SUB_PROG
– X X T_SUB_PROG
– X X M6_SUB_PROG
X – – D_SUB_PROG
X – X M6_SUB_PROG
X X – T_SUB_PROG
X X X M6_SUB_PROG
Note
Configuration of MD10718 $MN_M_NO_FCT_CYCLE_PAR:
The configuration of a replacement subroutine for the tool change with M code is dependent
on whether the tool change with M code was actually configured with
MD22550 $MC_TOOL_CHANGE_MODE.
