Detailed Description
2.4 Frames
Axis Types, Coordinate Systems, Frames (K2)
2-112 Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
MD20110 $MC_RESET_MODE_MASK
Bit 0 = 1 and bit 14 = 0 Chained complete basic frame is deleted.
Bit 0 = 1 and bit 14 = 1 The complete basic frame results from
$MC_BASEFRAMES_RESET_MASK
and
$MN_BASEFRAMES_RESET_MASK.
$MC_BASEFRAMES_RESET_MASK:
Bit 0 = 1: 1st channel basic frame is calculated into the chained
complete basic frame.
Bit 7 = 1: 8th channel basic frame is calculated into the chained
complete basic frame.
$MN_BASEFRAMES_RESET_MASK:
Bit 0 = 1: 1st NCU global basic frame is calculated into the chained
complete basic frame.
Bit 7 = 1: 8th NCU global basic frame is calculated into the chained
complete basic frame.
Programmable frame Deleted
Settable frames Retained, depending on
MD20110 $MC_RESET_MODE_MASK
and
MD20152 $MC_GCODE_RESET_MODE.
Complete basic frame Retained, depending on
MD20110 $MC_RESET_MODE_MASK bit 0 and bit 14
and on
MD10613 $MN_NCBFRAME_RESET_MASK
and
MD24002 $MC_CHBFRAME_RESET_MASK.
System frames Retained, depending on
MD24006 $MC_CHSFRAME_RESET_MASK
and
MD20150 $MC_GCODE_RESET_VALUES[ ].
Zero offset external Retained
DRF offset Retained
On RESET, system frames in the data management can be deleted using machine data
MD24007 $MC_CHSFRAME_RESET_CLEAR_MASK
