Detailed description
2.9 Assignment overview
Power Line Basic PLC Program (P3)
Function Manual, 08/2005 Edition, 6FC5397-0BP10-0BA0
2-73
Overview of data blocks
DB no. Designation Name Package
19 MMC interface
20 PLC machine data
21 - 30 CHANNEL 1 ... n Interface NC channels BP
BP 31 - 61 AXIS 1 ... m Interfaces for axes/spindles
or free for user assignment
62 - 70 Free for user assignment
71 - 74 Tool management BP
75 - 76 M group decoding
77 - 80 Reserved for Siemens
81 - 89 See below: ShopMill, ManualTurn
81 –127
1)
user area
1)
The actual upper limit of the block number (DB) depends on the current PLC CPU. See section "Key
PLC CPU data for 810D, 840D".
Note
The data blocks of channels, axes/spindles and tool management functions that are not
activated may be assigned as required by the user.
ManualTurn
ManualTurn uses FC 30 to 35 and DB 81 to 89.
ManualTurn is an operating system for conventional, cyclecontrolled turning machines. The
above FCs and DBs can be used provided that the machine to be configured is not a turning
machine with a maximum of two axes and one spindle. If your machine is of this type and if
you might require conventional operating methods in addition to CNC functions, then you
should not use the FCs and DBs above.
ShopMill
ShopMill uses FC30 to 35 and DB 81 to 89.
ShopMill is an operating system for 2 1/2D milling machines in the workshop environment.
The above FCs and DBs can be used provided that the machine to be configured is not a
milling machine for 2 1/2D machining operations. However, if you intend to use your machine
for applications of this type, then the FCs and DBs should not be used.
