Bay–related configuration data
0100 DESIGN DATA: Config. Bay 01 ?
0101 TYPE :B01 =feeder bay (section–isolat, bus–coupler, feeder bay)
0102 DESIGNA:B01 =1.0 (min. 0.0 – max. 99.9)
0103 BAY STA:B01 =existent (existent, non existent)
0104 CT LOC :B01 =line side (bus side, line side, non existent)
0105 CT POL :B01 =line side (bus side, line side)
0106 CT NORM:B01 =0.001 (min. 0.001 – max. 1.000)
0107 BZ–ISO1:B01 =on BZ01 (min. 000.00 – max. 123.24)
0
non existent,
1 ... 12
on BZ01 ... BZ12,
13 ...24
on AB01 ... AB12,
1.2...23.24
on BZ01/BZ02...AB11/AB12
101...124
on BZ01 ON...
....AB12 ON
101.2 ...
on BZ01/BZ02ON ...
123.24
on AB11/AB12ON
0108 BZ–ISO2:B01 =non existent (like BZ–ISO1)
0109 BZ–ISO3:B01 =non existent (like BZ–ISO1)
0110 BZ–ISO4:B01 =non existent (like BZ–ISO1) 1)
0111 BZ–ISO5:B01 =non existent (non existent, existent)
0200 DESIGN DATA: Config. Bay 02 ?
.
.
.
4800 CONFIGURAT: Config. Bay 48 ?
_______________
Function of isolator 4 depends an DA 5404/ZE
