Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
101
A.2.21
HMI basic parameters
Read access (r) to the HMI basic parameters is possible via Function Codes 03 and 04.
Write access (w) is possible for individual HMI basic parameters via function codes 06 and
16.
Register
Byte
Data format
Parameters
Range of values
[encoding]
Increment
3RW5
HMI HF
1)
[D*]
Address
high / low
0xB100 high Unsigned8 Language
[0 ... 254]
- r/w
[0]
[0] English
[1] German
[2] French
[3] Spanish
[4] Italian
[5] Chinese
[6] Portuguese
[254] Loadable language
0xB101 high Unsigned16 Display shutdown delay 1 … 60 min
[1 … 60]
1 min r/w
[5]
[0] Deactivated
0xB102 high Bool Display time
[0 ... 1]
- r/w
[0]
[0] Disable
[1] Enable
0xB103 high Bool Do Control After Logoff
[0 … 1]
- r/w
[0]
[0] Stop motor and give back control
[1] Continue with motor control
1)
Supported by 3RW5 HMI High Feature
* Default coding
