Configuring
6.3 Operation on failure of the bus connection to the controller
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
45
6.3
Operation on failure of the bus connection to the controller
An interruption in the connection between the 3RW5 soft starter and the controller must not
result in an undefined plant status.
Depending on the 3RW5 soft starter, you can set parameters that define the behavior of the
3RW5 soft starter on interruption of the connection with the controller in "Automatic" mode.
The 3RW52 soft starter does not support the parameters. If there is a connection interruption
to the controller, all the bits of the process image outputs (PIQ) are set to 0.
Parameters
Parameters
Description
Response to CPU / Master Stop With this parameter, you define how the 3RW5 soft starter will behave if a
CPU / Master stop occurs:
• Last value
The 3RW5 soft starter does not change the process image output. The current
control commands are retained.
• Substitute value (factory setting)
The process image output of the 3RW5 soft starter is automatically changed to
the values defined in the following parameter "Substitute value".
Substitute value* In the event of a bus failure, the 3RW5 soft starter is controlled by a corresponding
substitute process image output (depending on the 3RW5 soft starter).
• Motor CW
• Motor CCW
• Reset
• Emergency start
• Creep speed
• Output 1
• Output 2
• Parameter set bit 0
• Parameter set bit 1
• Disable Quick-stop
• Output 3
• Pump cleaning mode
• Manual operation local - input controlled
• Use alternative stopping mode
• Motor standstill
* In the 3RW5
HMI High Feature, the parameter is only visible if "Substitute value" is selected in the parameter
"Response to CPU / Master Stop".
