Configuring
6.2 Configuring the 3RW5 Soft Starter
SIRIUS 3RW5 Modbus TCP communication module
42 Manual, 03/2018, A5E43676481002A/RS-AA/001
Configuring 3RW5 soft starters with the aid of a 3RW5 HMI High Feature
Requirements
● Input device (3RW5 HMI High Feature, PC)
● Switched on control supply voltage on the 3RW5 soft starter
Programmable logic controller / client (e.g. SIMATIC S7-1500)
PC or programming device with configuration software of controller and Modbus client (optional)
SIRIUS 3RW5 soft starter / server
PC with SIRIUS Soft Starter ES (TIA Portal)
3RW5 HMI High Feature (accessories depend on 3RW5 soft starter)
... : Steps to be taken in the procedure
