Page #76 background imageLoading...
Page #76 background image
Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
76 Manual, 03/2018, A5E43676481002A/RS-AA/001
A.2.3
Memory image
Hexadecimal address
Chapter
Commands
0x0000 Node flash test (Page 76)
Identification data
0x00C1 I&M0 - Communication (Page 77)
0x0181
I&M0 - Basic unit (Page 77)
0x01A1
I&M1 - Basic unit (Page 78)
0x01C1
I&M2 - Basic unit (Page 78)
0x01E1
I&M3 - Basic unit (Page 78)
0x0241
I&M0 - HMI HF (Page 79)
Energy management (Page 79)
0x09C1
Phase current I L1 (rms)
0x09C3
Phase current I L2 (rms)
0x09C5
Phase current I L3 (rms)
0x09C7
Phase current average (rms)
0x0A47
Active power PL1..3
0x0A61
Active energy import (total)
3RW5 basic unit
0x8000
Process image input (PII) (Page 80)
0x8200
Process image output (PIQ) (Page 81)
0x8400
Soft starter diagnostics (Page 82)
0x8800
Measured values (Page 86)
0x8C00
Statistic data (Page 87)
0x9000 Maximum pointer (Page 88)
0x9400
Parameters (Page 89)
Modbus TCP communication
0xA100
Communication parameters (Page 99)
3RW5 HMI High Feature
0xB000
HMI diagnostics (Page 100)
0xB100
HMI parameters (Page 101)
A.2.4
Node flash test
For the station flash test (Node flash test) only write access (w) is possible via Function
Codes 05 and 06.
Register address
Bit address
Content
Access
0x0000
0x0000
Node flash test start
w
0x0001
Node flash test end
w
0x0002 ... 0x0015
Reserved
-
