Siemens SIRIUS 3RW5 series - 4 Mounting and Dismantling; Mounting the 3 RW5 Communication Module; Mounting the 3 RW5 Communication Module on the 3 RW5 Soft Starter

SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
29
Mounting and dismantling
4
4.1
Mounting the 3RW5 communication module
4.1.1
Mounting the 3RW5 communication module on the 3RW5 Soft Starter
Requirements
● 3RW5 soft starter
NOTICE
Damage to property due to electrical voltage
Switch off the power to the 3RW5 soft starter before starting work
(main and control supply voltage).
Procedure
1. Break out the cover of the slot. (Page 30)
2. Mount the 3RW5 communication module. (Page 32)
Result
You have mounted the 3RW5 communication module in the 3RW5 soft starter, which you
can connect to the fieldbus (Page 35) via the 3RW5 communication module.
