SIRIUS 3RW5 Modbus TCP communication module
80 Manual, 03/2018, A5E43676481002A/RS-AA/001
A.2.12
Process image input (PII)
For access to the process image input (PII) only read access (r) is possible via Function
Codes 01, 02, 03, 04 and 23.
Register
Byte
Bit address
Data format
Process image
3RW
Address
high / low
52
1)
55
2)
0x8000 high
0x8000
Bool
Ready (automatic)
r
r
0x8001
Bool
Motor On
r
r
0x8002
Bool
Group error
r
r
0x8003
Bool
Group warning
r
r
0x8004 Bool Input 1 r r
0x8005
Bool
Input 2
-
r
0x8006
Bool
Input 3
-
r
0x8007
Bool
Input 4
-
r
low
0x8008
Bool
Motor current Iact-bit0
r
r
0x8009
Bool
Motor current Iact-bit1
r
r
0x800A
Bool
Motor current Iact-bit2
r
r
0x800B
Bool
Motor current Iact-bit3
r
r
0x800C
Bool
Motor current Iact-bit4
r
r
0x800D
Bool
Motor current Iact-bit5
r
r
0x800E
Bool
Manual operation local
r
r
0x800F
Bool
Ramp operation
r
r
0x8001 high
0x8010
Bool
Motor CW
r
r
0x8011
Bool
Motor CCW
-
r
0x8014
Bool
Start mode active
r
r
0x8015
Bool
Operation / bypass active
r
r
0x8016
Bool
Stop mode active
r
r
0x8017
Bool
Test operation active
-
r
low
0x8018
Bool
Thermal motor model overload
r
r
0x8019 Bool Temperature sensor overload r r
0x801A
Bool
Switching element overload
r
r
0x801B
Bool
Cooling time active
r
r
0x801C
Bool
Device error
r
r
0x801D
Bool
Automatic parameterization active
-
r
0x8002
high
0x8020
Float32
Measured value 1
r
r
0x8004
high
0x8040
Float32
Measured value 2
r
r
0x8006
high
0x8060
Float32
Measured value 3
r
r
1)
Supported by SIRIUS 3RW52 soft starter
2)
Supported by SIRIUS 3RW55 soft starter
