3.5 Operating modes and master control function
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
25
3.5
Operating modes and master control function
The following modes are available (in ascending order of priority):
Operating mode
Control source
Control of the 3RW5 soft starter
Priority
Automatic
Fieldbus
Modbus client (e.g. PLC) controls
Lowest
Manual
operation
local
- - Connection abort (depending on the 3RW5 soft starter
and parameterization)
-
Input controlled
Digital inputs
Input actions control
↓
3RW5 HMI controlled 3RW5 HMI 3RW5 HMI controlled ↓
PC controlled
Local interface
SIRIUS Soft Starter ES (TIA Portal) controlled
Highest
If the connection to the control source is aborted, the control priority automatically switches
back to the lowest priority of the current mode.
Depending on the 3RW5 soft starter and the parameter assignment, the lowest priority in
operating mode "Manual operation local" is "Input controlled" in the following cases:
● 3RW52 soft starter
● 3RW55 soft starter with one of the following parameter assignments:
– Input action "Manual operation local" is parameterized and switched on.
– A controlling input action (e.g. "Motor CW") is parameterized, but the input action
"Manual operation local" is not parameterized.
