Siemens SIRIUS 3RW5 series User Manual

Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
79
A.2.10
I&M0 - HMI HF
For the device overview (I&M0) only read access (r) is possible via Function Codes 03
and 04.
Register
Content
Access
Address
Quantity
0x0241
5
RESERVED
r
0x0246
1
MANUFACTURER_ID
r
0x0247
10
ORDER_ID
r
0x0251
8
SERIAL_NUMBER
r
0x0259 1 HARDWARE_REVISION r
0x025A
2
SOFTWARE_REVISION
r
0x025C
1
REV_COUNTER
r
0x025D
1
PROFILE_ID
r
0x025E
1
PROFILE_SPECIFIC_TYPE
r
0x025F
1
IM_VERSION
r
0x0260
1
IM_SUPPORTED
r
A.2.11
Energy management
Only read access (r) to the energy management is possible via Function Codes 03 and 04.
Register
Data format
Content
3RW
Address
Quantity
52
1)
55
2)
0x09C1
2
Float32
Phase current I L1 (rms)
r
r
0x09C3
2
Float32
Phase current I L2 (rms)
r
r
0x09C5
2
Float32
Phase current I L3 (rms)
r
r
0x09C7
2
Float32
Phase current average (rms)
r
r
0x0A47
2
Float32
Active power PL1..3
-
r
0x0A61
2
Float32
Active energy import (total)
-
r
1)
Supported by SIRIUS 3RW52 soft starter
2)
Supported by SIRIUS 3RW55 soft starter
