SIRIUS 3RW5 Modbus TCP communication module
86 Manual, 03/2018, A5E43676481002A/RS-AA/001
A.2.15
Measured values
Only read access (r) to the measured values is possible via Function Codes 03 and 04.
Register
Byte
Data format
Measured value
Range of
values
Increment
3RW
Address
high / low
52
1)
55
2)
0x8801
high
Unsigned8
Phase current I L1 (%)
0 … 796.9 %
3.125 %
r
r
low
Unsigned8
Phase current I L2 (%)
0 … 796.9 %
3.125 %
r
r
0x8802 high Unsigned8 Phase current I L3 (%) 0 … 796.9 % 3.125 % r r
0x8803
high
Unsigned16
Remaining motor cooling time
0 … 1 800 s
0.1 s
r
r
0x8804 low Unsigned8 Asymmetry 0 … 100 % 1 % - r
0x8805
high
Unsigned16
Motor temperature rise
0 … 1 000 %
1 %
r
r
0x8809
high
Unsigned8
Output frequency
0 … 100 Hz
0.5 Hz
-
r
0x880B
high
Unsigned8
Line frequency
0 … 100 Hz
0.5 Hz
-
r
0x880C
high
Unsigned16
Line-to-line voltage U L1-L2
0 … 1 500 V
0.1 V
-
r
0x880D
high
Unsigned16
Line-to-line voltage U L2-L3
0 … 1 500 V
0.1 V
-
r
0x880E
high
Unsigned16
Line-to-line voltage U L3-L1
0 … 1 500 V
0.1 V
-
r
0x880F high Signed32 Phase current I L1 (rms) -20 000 …
20 000 A
0.01 A r r
0x8811 high Signed32 Phase current I L2 (rms) -20 000 …
20 000 A
0.01 A r r
0x8813 high Signed32 Phase current I L3 (rms) -20 000 …
20 000 A
0.01 A r r
0x8816
low
Unsigned8
Switching element heating
0 … 250 %
1 %
r
r
0x8817
high
Unsigned16
Remaining switching element cooling time
0 … 1 800 s
0.1 s
r
r
0x8818
high
Unsigned16
Remaining time for motor overload protection
0 … 6 500 s
0.1 s
-
r
0x8819 high Signed32 Active power PL1..3 -2 147 483 …
2 147 483 W
0.1 W - r
0x881B high Unsigned16 Torque 0 …
65 535 Nm
1 Nm - r
0x881C
high
Unsigned8
Power factor L1..3
0 … 1
0.01
-
r
0x8820 high Unsigned16 Remaining switching frequency monitoring
time
0 … 65 535 s 1 s - r
0x8821
high
Unsigned8
Phase current average (%)
0 … 796.9 %
3.125 %
r
r
0x8823 high Signed32 Phase current average (rms) -20 000 …
20 000 A
0.01 A r r
0x8825 high Signed32 Maximum phase current (rms) -20 000 …
20 000 A
0.01 A - r
1)
Supported by SIRIUS 3RW52 soft starter
2)
Supported by SIRIUS 3RW55 soft starter
