Appendix
A.2 Data tables
SIRIUS 3RW5 Modbus TCP communication module
Manual, 03/2018, A5E43676481002A/RS-AA/001
85
Register
Byte
Bit address
Data format
Soft starter diagnostics
3RW
Address
high / low
52
1)
55
2)
0x841B
low
0x85B8
Bool
Pump cleaning active
-
r
0x841C
high
0x85C5
Bool
Analog output underflow
-
r
low 0x85CD Bool Analog output overflow - r
0x841E
high
0x85E0
Bool
Missing initialization after maintenance
r
r
low
0x85E8
Bool
Monitoring of switching frequency time running
-
r
0x85E9
Bool
Switching frequency time error
-
r
0x85EB
Bool
Switching frequency time error
-
r
0x85EF
Bool
Switching frequency lock active
-
r
0x841F high
0x85F0
Bool
Emergency operation enabled
-
r
0x85F1
Bool
Emergency operation active
-
r
0x85F2
Bool
Emergency start enabled
-
r
low
0x85F9
Bool
Alternative stopping mode active
-
r
0x8420 low
0x8608
Bool
Main power rotation faulty
-
r
0x860B
Bool
Main power rotation faulty
-
r
0x8421
low
0x861D
Bool
Check fan
r
r
0x8422 low
0x8629
Bool
Load missing
-
r
0x862C
Bool
Supply voltage too high
-
r
0x862F
Bool
No main power
r
r
0x8423 high
0x8631
Bool
Phase failure L1
-
r
0x8633
Bool
Phase failure L2
-
r
0x8635
Bool
Phase failure L3
-
r
0x8424 low 0x864A Bool Active power warning limit exceeded - r
0x864B
Bool
Active power warning limit undershot
-
r
0x864C
Bool
Active power error limit exceeded
-
r
0x864D
Bool
Active power error limit undershot
-
r
0x864E
Bool
Active power error limit shutoff
-
r
0x8426 low
0x8668
Bool
Supply voltage not permitted for test
-
r
0x8669
Bool
Supply voltage required for test
-
r
0x866D
Bool
Test with small load active
-
r
0x8428 high
0x8680
Bool
Operating temperature too high
r
r
0x8688
Bool
Automatic parameterization active
-
r
0x8429 high
0x8692
Bool
Starting time warning limit exceeded
-
r
0x8693
Bool
Starting time warning limit undershot
-
r
low
0x8698
Bool
Logbook application - error deleted
r
r
0x869A
Bool
Logbook application - warning deleted
-
r
0x869C
Bool
Logbook application - event deleted
-
r
0x869D
Bool
Logbook service - error deleted
-
r
0x869F
Bool
Logbook service - event deleted
-
r
1)
Supported by SIRIUS 3RW52 soft starter
2)
Supported by SIRIUS 3RW55 soft starter
3)
Object number of the incorrect parameter from the data table "Parameters"
